Xentino MR401 4G/LTE Hücresel Geniş bant Endüstriyel Yönlendiricidir. Endüstriyel uygulamalar için son derece güvenilir ve güvenli ağ iletişimi sağlar. 1xWAN, 3xLAN, 2xRS232, 1xRS485, 2xSMA Anten konnektörü (MAIN+AUX), 2xDI, 1xDO, 2xSIM Kart Yuvası, -20 ~ +70°C. (Endüstriyel Güç kaynağı haricen alınmalı, 24V 2A Endüstriyel Güç kaynağı kullanılmalıdır.)
Xentino MR401 serisi 4G / LTE Hücresel Yönlendiricidir, endüstriyel ağlar için tasarlanmış son derece güvenilir ve güvenli kablosuz iletişim ağ geçididir. Çok çeşitli uygulamalar ve dikey machine-to-machine (M2M) pazarları için FDD / TDD LTE, WCDMA ve GSM gibi çoklu bant bağlantılarını destekler. Güvenilirliği arttırmak için, MR401 serisi, kritik hücresel iletişim için kesintisiz bağlantıyı sağlamak üzere yük devretmeyi ve dolaşımını destekleyen çift SIM yuvası ile donatılmıştır. 1 x WAN, 3 x LAN, 2 x RS232, 1 x RS485, Antenna Connector 2 x SMA ( MAIN + AUX), 2 x DI, 1 x DO, 2 x SIM Kart Yuvaları, -20 ~ + 70 ° C
Xentino MR401 series 4G/LTE Cellular Routers are highly reliable and secure wireless communications gateway designed for industrial networking. It supports multi-band connectivity including FDD/TDD LTE, WCDMA and GSM for a wide range of applications and vertical machine-to-machine (M2M) markets. To enhance reliability, MR401 series are equipped with dual SIM that supports failover and roaming over to ensure uninterrupted connectivity for mission-critical cellular communications.
With flexible LAN/WAN Ethernet options, MR401 series allow you to customize your professional applications in diverse environments. It also provides enterprise-grade software features, such as Quality of Service (QoS) for traffic prioritization, IPSec, OpenVPN, Firewall security and etc. The device are administrated via web GUI, Telnet, SSH v2 and HTTP/HTTPS.
Built for secure and uninterrupted operation in harsh environments, MR401 series support extended operating temperature from -20 to +70°C and a flexible input voltage range of 10-32V DC. Xentino MR401 series are ideal cellular communications solution for heavy industrial use.
Key Features
Specifications
LTE Interface
Processor & I/O Interface
Physical Characteristics
LED Display
Power Supply
MTBF (mean time between failures)
Software Network Protocols:
|
Routing/Firewall:
VPN:
Wireless Connectivity:
Others:
Alarm:
Management Software
Environment
Standards and Certifications
EN 61000-4-3 (RS) Level 3 / EN 61000-4-4 (EFT) Level 4 / EN 61000-4-5 (Surge) Level 3 / EN 61000-4-6 (CS) Level 3 / EN 61000-4-8 (PFMF) Level 4 / EN 61000-4-11 / EN 61000-6-2 (Industrial) / EN 61000-6-4 (Industrial)
|
