QSAN XCubeSAN XS1226S 2U 26 Bay(2.5inch) Rackmount SAN (Single Ctrl)
2U 2.5inch 26Bay RackMount Active-Active Dual Controller (Optional) SAN (Storage Area Network) Storage System. Supports both iSCSI IP-SAN and FC-SAN with high performance. Dual-Controller SAN System, iSCSI, RAID 0,1, 5, 6, 10, 50, 60, global hot spare, max 32GB RAM, 4-port 10GbE BASE-T iSCSI, redundant power supply, 4 slots for optional host cards.
2U 2.5inch 26Bay RackMount Active-Active Dual Controller (Optional) SAN (Storage Area Network) Storage System. Supports both iSCSI IP-SAN and FC-SAN with high performance. Dual-Controller SAN System, iSCSI, RAID 0,1, 5, 6, 10, 50, 60, global hot spare, max 32GB RAM, 4-port 10GbE BASE-T iSCSI, redundant power supply, 4 slots for optional host cards.
The XCubeSAN XS1200 series is the newest of the XCubeSAN Series available from QSAN. It is an active-active dual controller SAN (Storage Area Network) storage system series, supporting both iSCSI IP-SAN and FC-SAN with high performance. Additionally, it simplifies the SAN deployment in the IT infrastructure, combining enterprise essential features such as thin provisioning, SSD read/write cache, auto tiering, snapshot, local volume clone, remote replication, scalable to PB level capacity, etc., in one box.
| Hardware | |
| RAID Controller | Dual-active controller (Model : XS1224D / XS1216D / XS1212D / XS1226D) |
| Single-upgradable controller (Model : XS1224S / XS1216S / XS1212S / XS1226S) | |
| Processor | Intel® 2-core processor |
| Memory (per Controller) | DDR4 ECC 4GB, up to 32GB (two DIMM slots, insert two DIMMs or more will boost performance) |
| * To support QCache, the minimum memory per controller is 8GB | |
| Host Connectivity (per Controller) | Host Card Slot 1 (optional) |
| 4 x 16Gb FC (SFP+) ports | |
| 2 x 16Gb FC (SFP+) ports | |
| 4 x 10GbE iSCSI (SFP+) ports | |
| 2 x 10GbE iSCSI (RJ45) ports | |
| 4 x 1GbE iSCSI (RJ45) ports | |
| Host Card Slot 2 (optional) | |
| 4 x 16Gb FC (SFP+) ports (Slot 2 provides 20Gb bandwidth) | |
| 2 x 16Gb FC (SFP+) ports (Slot 2 provides 20Gb bandwidth) | |
| 4 x 10GbE iSCSI (SFP+) ports (Slot 2 provides 20Gb bandwidth) | |
| 2 x 10GbE iSCSI (RJ45) ports | |
| 4 x 1GbE iSCSI (RJ45) ports | |
| Onboard | |
| 2 x 10GBASE-T iSCSI ports | |
| 1 x 1GbE management port | |
| Expansion Connectivity (per Controller) | Built-in 2 x 12Gb/s SAS wide ports (SFF-8644) |
| Drive Type | XS1224 / XS1216 / XS1212 |
| Mix & match 3.5" 2.5" SAS, NL-SAS, SED HDD | |
| 2.5” SAS, SATA SSD (6Gb MUX board needed for 2.5" SATA drives in dual controller system) | |
| XS1226 | |
| 2.5" SAS, NL-SAS, SED HDD | |
| 2.5” SAS, SATA SSD (6Gb MUX board needed for 2.5" SATA drives in dual controller system) | |
| Expansion Capabilities | Up to 10 expansion units using XD5300 series 12Gb SAS expansion enclosure |
| XD5324 (4U 24-bay, LFF) | |
| XD5316 (3U 16-bay, LFF) | |
| XD5312 (2U 12-bay, LFF) | |
| XD5326 (2U 26-bay, SFF) | |
| Max. Drives Supported | XS1224 (4U 24-bay, LFF) : 624 |
| XS1216 (3U 16-bay, LFF) : 616 | |
| XS1212 (2U 12-bay, LFF) : 612 | |
| XS1226 (2U 26-bay, SFF) : 626 | |
| Dimension (H x W x D) | MAYIS” Rackmount |
| XS1224 (4U 24-bay, LFF) : 170.3 x 438 x 515 mm | |
| XS1216 (3U 16-bay, LFF) : 130.4 x 438 x 515 mm | |
| XS1212 (2U 12-bay, LFF) : 88 x 438 x 515 mm | |
| XS1226 (2U 26-bay, SFF) : 88 x 438 x 491 mm | |
| Memory Protection | Cache-to-Flash module (optional) |
| Battery backup module + Flash module (to protect all memory capacity) | |
| Super capacitor module + Flash module (to protect up to 16GB memory per controller) | |
| LCM (LCD Module) | USB LCM (optional) |
| Power Supply | 80 PLUS Platinum, two redundant 770W (1+1) |
| AC Input | |
| 100~127V 10A, 50-60Hz | |
| 200~240V 5A, 50-60Hz | |
| DC Output | |
| +12V 63.4A | |
| +5VSB 2.0A | |
| Fan Module | 2 x hot pluggable/redundant fan modules |
| Software | |
| Storage Management | RAID level 0 ,1 ,0+1 ,3 ,5 ,6 ,10 ,30 ,50, 60, and N-way mirror |
| RAID EE level 5EE, 6EE, 50EE, and 60EE | |
| Flexible storage pool ownership | |
| Thin Provisioning (QThin) with space reclamation | |
| SSD Cache (QCache1) | |
| Auto Tiering (QTiering1) | |
| Global, local, and dedicated hot spares | |
| Write-through and write-back cache policy | |
| Online disk roaming | |
| Spreading RAID disks drives across enclosures | |
| Background I/O priority setting | |
| Instant RAID volume availability | |
| Fast RAID rebuild | |
| Online storage pool expansion | |
| Online RAID level migration | |
| Online volume extension | |
| Online volume migration2 | |
| Auto volume rebuilding | |
| Instant volume restoration | |
| SED & ISE drive support | |
| Video editing mode for enhanced performance | |
| Disk drive health check and S.M.A.R.T. attributes | |
| Storage pool parity check and media scan for disk scrubbing | |
| SSD wear lifetime indicator | |
| Disk drive firmware batch update | |
| iSCSI Host Connectivity | Proven QSOE 2.0 optimization engine |
| CHAP & mutual CHAP authentication | |
| SCSI-3 PR (Persistent Reservation for I/O fencing) support | |
| iSNS support | |
| VLAN (Virtual LAN) support | |
| Jumbo frame (9,000 bytes) support | |
| Up to 256 iSCSI targets | |
| Up to 512 hosts per controller | |
| Up to 1,024 sessions per controller | |
| Fibre Channel Host Connectivity | Proven QSOE 2.0 optimization engine |
| FCP-2 & FCP-3 support | |
| Auto detect link speed and topology | |
| Topology supports point-to-point3 and loop | |
| Up to 256 hosts per controller | |
| High Availability | Dual-Active (Active/Active) SAN controllers |
| Cache mirroring through NTB bus | |
| ALUA support | |
| Management port seamless failover | |
| Fault-tolerant and redundant modular components for SAN controller, PSU, FAN module, and dual port disk drive interface | |
| Dual-ported HDD tray connector | |
| Multipath I/O and load balancing support (MPIO, MC/S, Trunking, and LACP) | |
| Firmware update with zero system downtime | |
| Security | Secured Web (HTTPS), SSH (Secure Shell) |
| iSCSI Force Field to protect from mutant network attack | |
| iSCSI CHAP & mutual CHAP authentication | |
| SED & ISE drive support | |
| Storage Efficiency | Thin Provisioning (QThin) with space reclamation |
| Auto Tiering (QTiering1) with 3 levels of storage tiers | |
| Networking | DHCP, Static IP, NTP, Trunking, LACP, VLAN, Jumbo frame (up to 9,000 bytes) |
| Advanced Data Protection | Snapshot (QSnap), block-level, differential backup |
| Writeable snapshot support | |
| Manual or schedule tasks | |
| Up to 64 snapshots per volume | |
| Up to 64 volumes for snapshot | |
| Up to 4,096 snapshots per system | |
| Remote Replication (QReplica) | |
| Asynchronous, block-level, differential backup based on snapshot technology | |
| Traffic shaping for dynamic bandwidth controller | |
| Manual or schedule tasks | |
| Auto rollback to previous version if current replication fails | |
| Up to 32 schedule tasks per controller | |
| Volume clone for local replication | |
| Configurable N-way mirroring | |
| Integration with Windows VSS (Volume Shadow Copy Service) | |
| Instant volume restoration | |
| Cache-to-Flash memory protection1 | |
| M.2 flash module | |
| Power module: BBM (Battery Backup Module) or SCM (Super Capacitor Module) | |
| Support USB UPS and network UPS with SNMP management | |
| Virtualization Certification | Server Virtualization & Clustering |
| Latest VMware vSphere certification | |
| VMware VAAI for iSCSI & FC | |
| Windows Server 2016, 2012 R2 Hyper-V certification | |
| Microsoft ODX | |
| Latest Citrix XenServer certification | |
| Easy Management | USB LCM1, serial console support, online firmware update |
| Intuitive Web management UI, secured web (HTTPS), SSH (Secured Shell), LED indicators | |
| S.E.S. support, S.M.A.R.T. support, Wake-on-LAN, and Wake-on-SAS | |
| Green & Energy Efficiency | 80 PLUS Platinum power supply |
| Wake-on-LAN to turn on or wake up the system only when necessary | |
| Auto disk spin-down | |
| Host Operating Systems Support | Windows Server 2008, 2008 R2, 2012, 2012 R2, 2016 |
| SLES (SUSE Linux Enterprise Server) 10, 11, 12 | |
| RHEL (Red Hat Enterprise Linux) 5, 6, 7 | |
| CentOS (Community ENTerprise Operating System) 6, 7 | |
| Solaris 10, 11 | |
| Free BSD 9, 10 | |
| Mac OS X 10.11 or later | |
| Warranty & Regulatory | |
| Warranty | System : 3 years |
| Battery backup module : 1 year | |
| Super capacitor module : 1 year | |
| Regulatory | CE, FCC, BSMI, VCCI, KCC |
| Operating Environment | |
| Temperature | Operating temperature : 0 to 40°C |
| Shipping temperature : -10 to 50°C | |
| Relative Humidity | Operating relative humidity : 20% to 80% non-condensing |
| Non-operating relative humidity : 10% to 90% | |
