Xentino S402GP üzerinde4adet 10/100/1000Mbps PoE desteğine sahip ethernet portu, 2adet 10/100/1000Mbps Ethernet (RJ45) portu bulunan yönetilemez network switchtir. 65W PoE güç kaynağı mevcuttur.
OVERVIEW
The S402GP is a gigabit unmanaged PoE switch independently developed by Xentino. It has 4*10/100/1000M PoE ports and 2*10/100/1000M uplink RJ45 ports. Port 1-4 can support IEEE802.3af/at standard PoE. Single port PoE power reaches 30W, and the maximum PoE output power is 65W (at-110W). As a PoE power supply device, it can automatically detect and recognize the power receiving equipment that meets the standard and supply power through the network cable. It can supply power to POE terminal equipment such as wireless AP, webcam, VoIP, visual intelligent building intercom through network cable, and meet the network environment that needs high-density PoE power supply. It is suitable for hotel, campus, factory dormitory and small and medium-sized enterprises.
Unmanaged mode, plug and play, no configuration, easy to use.
FEATURES
XENTINO S402GP |
|
Interface Characteristics |
|
Fixed Port |
4*10/100/1000Base-T PoE port (Data/Power) 2*10/100/1000Base-T uplink RJ45 ports (Data) |
Ethernet Port |
10/100/1000Base-T auto-sensing, full/half duplex MDI/MDI-X self-adaption. |
Twisted Pair Transmission |
10BASE-T: Cat3,4,5 UTP(≤100 meter) 100BASE-TX: Cat5 or later UTP(≤100 meter) 1000BASE-T: Cat5e or later UTP(≤100 meter) |
Chip Parameter |
|
Network Protocol |
IEEE802.3 10BASE-T, IEEE802.3i 10Base-T IEEE802.3u 100Base-TX, IEEE802.3ab 1000Base-T, IEEE802.3x |
Forwarding Mode |
Store and Forward(Full Wire Speed) |
Switching Capacity |
16Gbps (Non-blocking) |
Forwarding Rate |
8.93Mpps (@64byte) |
MAC |
8K |
Buffer Memory |
2M |
Jumbo Frame |
10K |
LED Indicator |
Power: PWR (Green), Data:Link(Yellow), PoE: PoE (Green) |
Reset Switch |
Yes, One-button factory reset |
PoE & Power Supply |
|
PoE Port |
Port 1 to 4 IEEE802.3af/at @ POE |
Power Supply Pin |
Default 1/2(+),3/6(-), Optional 4/5(+),7/8(-) |
Max Power Per Port |
30W; IEEE802.3af/at |
Total PWR / Input Voltage |
65W (DC52V) |
Power Consumption |
Standby<5W, Full Load<65W |
Power Supply |
External power supply AC100~240V 50-60Hz 1.1A |
Physical Parameter |
|
Operation TEMP / Humidity |
-20~+55°C, 5%~90% RH Non condensing |
Storage TEMP / Humidity |
-40~+75°C, 5%~95% RH Non condensing |
Dimension |
118*95*28mm (L*W*H) |
Net /Gross Weight |
<0.35kg /<1.0kg |
Form Factor |
Desktop, Wall-mounted |
Certification & Warranty |
|
Lightning Protection / Protection Level |
Lightning protection: 4KV 8/20us, Protection level: IP30 |
Certification |
CCC, CE mark, commercial, CE/LVD EN60950, FCC Part 15 Class B, RoHS |
Warranty |
3 years, lifelong maintenance. |
