QSAN XCubeNAS XN7004R 4+2 Bay 1U Rackmount NAS

QSAN XCubeNAS XN7004R 4+2 Bay 1U Rackmount NAS

QSAN

Rackmount 1U 4+2 Bay with Intel Core i3 3.9 GHz Dual-Core CPU, 8GB DDR4 RAM (Max 64GB).

QSAN XCubeNAS XN7004R Özellikler

Hardware Specifications

Architecture All-in-one
Storage OS QSMSpecification Details
CPU
Processor Intel® Core i3
CPU Architecture 64-bit
CPU Frequency Dual-Core 3.9GHz
Memory
System Flash 8GB USB DOM
Memory Module Pre-installed 8GB DDR4 U-DIMM
Total Memory Slots 4
Memory Expandable up to 64 GB
Notes -
Storage
Drive Bays

3.5" Slot x 4

2.5" Slot x 2
Maximum Drive Bays with Expansion Unit 198
Compatible Drive Type

3.5" SATA HDD

2.5" SATA HDD

2.5" SATA SSD
Drive Interface

SATA 6Gb/s
(backward compatible with SATA 3Gb/s)
Maximum Internal Raw Capacity 72TB
Maximum Raw Capacity with Expansion Units 3138TB
Hot Swappable Drive
Notes
  • For more information, please refer to compatibility matrix and hardware manual
  • Maximum internal raw capacity= 16 TB drive x 4 + 3.84 TB drive x 2
  • Capacity may vary by RAID types
External Port
USB 2.0 Port 1 (Front)
USB 3.0 Port 4 (Rear)
HDMI Port 1
Others Console Port x1
Notes -
Connectivity Port
1GbE RJ45 LAN Port 4 (Onboard)
10GbE RJ45 LAN Port 2 (Option: THBE10R2)
10GbE SFP+ LAN Port 2 (Option: XN-E1002)
Thunderbolt 3 2 (Option: XN-TB302)
16Gb SFP+ Fibre Channel -
Notes

For more information, please refer to accessory book

Please refer to the section below for expansion slot specification
Expansion Port
12Gb/s SAS Wide Port 2 (Option: XN-S1202)
Notes For more information, please refer to accessory book
PCIe Expansion
Gen3x8 Slot 1
Gen3x4 Slot -
Notes For more information, please refer to hardware manual
Host Card Expansion
Gen3x8 Slot -
Gen2x4 Slot -
Notes -
Appearance
Dimension (H x W x D) (mm) 44 x 438 x 510
Chassis Form Factor 19" Rackmount 1U 4+2 Bay
Net Weight (kg) -
Gross Weight (kg) -
Notes
