QSAN XCubeNAS XN8008T 8+1 Bay Tower NAS

QSAN XCubeNAS XN8008T Özellikler

Hardware Specifications

CPU
Architecture	All-in-one
Storage OS	QSM Specification Details
Processor	Intel® Core™i5
CPU Architecture	64-bit
CPU Frequency	Quad-Core 2.7GHz
Memory
System Flash	8GB USB DOM
Memory Module Pre-installed	8GB DDR4 SO-DIMM
Total Memory Slots	2
Memory Expandable up to	32 GB
Notes	-
Storage
Drive Bays	3.5" Slot x 8 2.5" Slot x 1
Maximum Drive Bays with Expansion Unit	-
Compatible Drive Type	3.5" SATA HDD 2.5" SATA HDD 2.5" SATA SSD
Drive Interface	SATA 6Gb/s (backward compatible with SATA 3Gb/s)
Maximum Internal Raw Capacity	132TB
Maximum Raw Capacity with Expansion Units	-
Hot Swappable Drive
Notes	For more information, please refer to compatibility matrix and hardware manual Maximum internal raw capacity= 16 TB drive x 8 + 3.84 TB drive x 1 Capacity may vary by RAID types
External Port
USB 2.0 Port	-
USB 3.0 Port	5 (Front: 1, Rear: 4)
HDMI Port	1
Others	-
Notes	-
Connectivity Port
1GbE RJ45 LAN Port	4 (Onboard)
10GbE RJ45 LAN Port	2 (Option: THBE10R2)
10GbE SFP+ LAN Port	2 (Option: XN-E1002)
Thunderbolt 3	2 (Option: XN-TB302)
16Gb SFP+ Fibre Channel	-
Notes	For more information, please refer to accessory book Please refer to the section below for expansion slot specification
Expansion Port
12Gb/s SAS Wide Port	-
Notes	-
PCIe Expansion
Gen3x8 Slot	1
Gen3x4 Slot	-
Notes	For more information, please refer to hardware manual
Host Card Expansion
Gen3x8 Slot	-
Gen2x4 Slot	-
Notes	-
Appearance
Dimension (H x W x D) (mm)	177 x 310 x 235
Chassis Form Factor	Tower 8+1 Bay
Net Weight (kg)	4.8
Gross Weight (kg)	6
Notes	-
Memory Protection
Cache-to-Flash Module	-
Battery Backup Module + Flash Module	-
Notes	-
Others
System Fan	12am x 120mm x 2 pcs
Replaceable System Fan	-
Power Recovery
Scheduled Power On/Off
Wake on LAN/WAN
Power Supply Unit / Adapter	FLEX ATX 200W
Redundant Power Supply	-
AC Input Power Voltage	100V-240V
Power Frequency	50-60 Hz, Single Phase
Power Consumption	-
British Thermal Unit	-
LCM Support
Notes	-
Environment Temperature
Operating Temperature	0 to 40°C
Storage Temperature	-10°C to 50°C
Operating Relative Humidity	20% to 80% non-condensing
Non-operating Relative Humidity	10% to 90%
Notes	-
Certification
Certifications	CE FCC BSMI VCCI RCM SASO EAC
Notes	-
Warranty
Standard Warranty	2 years
Notes	-
