Rackmount 2U 12 Bay with Intel Core i3 3.9 GHz Quad-Core CPU, 8GB DDR4 RAM (Max 64GB).

Açıklamalar
Özellikler
Belgeler
Alternatif Ürünler
İlişkili Ürünler
Görseller

The XN7000R Series are next generation, highly efficient NAS systems which are designed for SMB and enterprise applications. The XN7000R Series are powered by the latest generation of Intel® Kaby Lake processors and up to 64GB of DDR4 ECC RAM. Intel® Core™ i3 3.9GHz Dual-Core Processor, 8GB DDR4 ECC U-DIMM, up to 64GB RAM, USB 3.0 x4 (Rear), USB 2.0 x1 (Front), Flash 8GB USB DOM Drive Bays 12 LFF with lock / 4 SFF (SATA SSD).

Hardware Specifications

CPU
Architecture	Single Controller
Storage OS	QSM 3 Specification Details
Processor	Intel® Core™i3
CPU Architecture	64-bit
CPU Frequency	Dual-Core 3.9GHz
Memory
System Flash	8GB USB DOM
Memory Module Pre-installed	8GB DDR4 U-DIMM
Total Memory Slots	4
Memory Expandable up to	64 GB
Notes	-
Storage
Drive Bays	3.5" Slot x 12
Maximum Drive Bays with Expansion Unit	204
Compatible Drive Type	3.5" SATA HDD 2.5" SATA HDD 2.5" SATA SSD
Drive Interface	SATA 6Gb/s (backward compatible with SATA 3Gb/s)
Maximum Internal Raw Capacity	MAYIS2TB
Maximum Raw Capacity with Expansion Units	3264TB
Hot Swappable Drive
Notes	For more information, please refer to compatibility matrix and hardware manual Maximum internal raw capacity= 16 TB drive x 12 Capacity may vary by RAID types
External Port
USB 2.0 Port	1 (Front)
USB 3.0 Port	4 (Rear)
HDMI Port	1
Others	Console Port x1
Notes	-
Connectivity Port
1GbE RJ45 LAN Port	4 (Onboard)
10GbE RJ45 LAN Port	2 (Option: RHBE10R2)
10GbE SFP+ LAN Port	2 (Option: XN-E1002)
Thunderbolt 3	2 (Option: XN-TB302)
16Gb SFP+ Fibre Channel	-
Notes	For more information, please refer to accessory book Please refer to the section below for expansion slot specification
Expansion Port
12Gb/s SAS Wide Port	2 (Option: XN-S1202)
Notes	For more information, please refer to accessory book
PCIe Expansion
Gen3x8 Slot	1
Gen3x4 Slot	-
Notes	For more information, please refer to hardware manual
Host Card Expansion
Gen3x8 Slot	-
Gen2x4 Slot	-
Notes	-
Appearance
Dimension (H x W x D) (mm)	88.5 x 438 x 510
Chassis Form Factor	MAYIS" Rackmount 2U 12 Bay
Net Weight (kg)	12.7
Gross Weight (kg)	14.1
Notes	-
Memory Protection
Cache-to-Flash Module	-
Battery Backup Module + Flash Module	-
Notes	-
Others
System Fan	60mm x 60mm x 3 pcs
Replaceable System Fan	YES
Power Recovery	YES
Scheduled Power On/Off	YES
Wake on LAN/WAN	YES
Power Supply Unit / Adapter	250W x2
Redundant Power Supply	YES
AC Input Power Voltage	100V-240V
Power Frequency	50-60 Hz, Single Phase
Power Consumption	300 W (Access) 168 W (HDD Hibernation)
British Thermal Unit	1023 BTU/hr (Access) 573 BTU/hr (HDD Hibernation)
LCM Support
Notes	-
Environment Temperature
Operating Temperature	0 to 40°C
Storage Temperature	-10°C to 50°C
Operating Relative Humidity	20% to 80% non-condensing
Non-operating Relative Humidity	10% to 90%
Notes	-
Certification
Certifications	CE FCC BSMI VCCI RCM
Notes	-
Warranty
Standard Warranty	3 years
Notes	-
