Ürün Bilgileri

Synology DS220Plus all in one 2Bay NAS Ev Kullancıları ve Küçük Şirketler için 2 adet SATA Yuvalı NAS Sunucusu. 2 Core 2.0Ghz İşlemcili, 2 adet Gigabit Ethernet portlu RAID1 yapabileceğiniz bir veri depolama ünitesi.

Compact and high performance NAS solution

Synology DS220+ is a compact network-attached storage solution designed to streamline your data and multimedia management. It features smooth data sharing, video streaming, and photo indexing, as well as well-rounded data protection and recovery options.

CPU ModelIntel Celeron J4025CPU Quantity1CPU Architecture64-bitCPU Frequency2-core 2.0 (base) / 2.9 (burst) GHzHardware Encryption Engine (AES-NI)

System Memory2 GB DDR4 non-ECCTotal Memory Slots1Maximum Memory Capacity6 GB (2 GB + 4 GB)Notes

• Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
• Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.

Drive Bays2Compatible Drive Type* (See all supported drives)

• 3.5" SATA HDD
• 2.5" SATA HDD
• 2.5" SATA SSD

Hot Swappable Drive*Notes"Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.

RJ-45 1GbE LAN Port2 (with Link Aggregation / Failover support)USB 3.2 Gen 1 Port*2USB / SD CopyNotesThe USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019.

Internal Drives

• Btrfs
• EXT4

External Drives

• Btrfs
• EXT4
• EXT3
• FAT
• NTFS
• HFS+
• exFAT

NotesexFAT Access can be installed for free from Package Center in DSM 7.0. In DSM 6.2 or earlier versions, exFAT Access needs to be purchased in Package Center.

Size (Height x Width x Depth)165 mm x 108 mm x 232.2 mmWeight1.30 kg

System Fan92 mm x 92 mm x 1 pcsFan Speed Mode

• Full-Speed Mode
• Cool Mode
• Quiet Mode

Brightness Adjustable Front LED IndicatorsPower RecoveryNoise Level*19.3 dB(A)Scheduled Power On / OffWake on LAN / WANPower Supply Unit / Adapter60 WAC Input Power Voltage100V to 240V ACPower Frequency50/60 Hz, Single PhasePower Consumption14.69 W (Access)
4.41 W (HDD Hibernation)British Thermal Unit50.12 BTU/hr (Access)
15.05 BTU/hr (HDD Hibernation)Notes

• Power consumption is measured when it is fully loaded with Western Digital 1TB WD10EFRX hard drive(s).
• Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%

Operating Temperature0°C to 40°C (32°F to 104°F)Storage Temperature-20°C to 60°C (-5°F to 140°F)Relative Humidity5% to 95% RH

• FCC
• CE
• BSMI
• EAC
• CCC
• KC
• VCCI
• RCM

2-year hardware warranty, extendable to 4 years with Extended Warranty PlusNotes

• Availability varies by region. Before purchasing, please visit the official web pages of EW201/202 and Extended Warranty Plus for a list of eligible regions.
• The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)

RoHS Compliant

• Main Unit X 1
• Accessory Pack X 1
• AC Power Adapter X 1
• AC Power Cord X 1
• RJ-45 LAN Cable X 2
• Quick Installation Guide X 1

• DDR4 non-ECC SODIMM: D4NESO-2666-4G
• 3.5" SATA HDD: HAT5300
• 2.5" SATA SSD: SAT5210
• VisualStation: VS360HD
• Surveillance Device License Pack

NotesAll memory modules will operate at the maximum frequency specified by the CPU manufacturer.
