Ürün Bilgileri

Availability and Resilience

• Dual-WAN Interface

• Auto fail-over and failback

• Load Balancing

Supported Frequency Bands *1

• Global LTE Bands FDD, TDD& 3G/2G Fallback options (Bands depend on module configuration)

Network Protocols and Features

• IPv4, IPv6, IPv4/IPv6 dual stack*2

• Dual APN*3

• Keep-Alive

• IP Pass-Through

• NAT, Virtual Server, and DMZ

• Static Routing, Dynamic Routing (RIP v1/v2, OSPF, BGP)

• SNTP, DNS relay and DDNS

• Universal Plug and Play(UPnP) compliant

• Supports DHCP server/client/relay

Firewall

• Built-in NAT Firewall

• Stateful Packet Inspection (SPI)

• Prevents DoS attacks including Land Attack, Ping of Death, etc.

• Access Control

• IP Filtering, MAC Filtering, URL Filtering

• Password protection for system management

• VPN Passthrough

VPN

• IPSec VPN Tunneling

• PPTP VPN Tunneling (dial-in/dial-out tunnels)

• L2TP over IPSec VPN Tunneling (dial-in/dial-out tunnel)

• OpenVPN VPN Tunneling

• GRE

Quality of Service Control

• Traffic prioritization based-on IP protocol, port number, and IP address

Wireless LAN

• Compliant with IEEE 802.11b/g/n standards

• Up to 300Mbps wireless operation rate

• WPS (Wi-Fi Protected Setup) for easy setup

• 64/128 bits WEP supported for encryption

• Wireless security with WPA-PSK, WPA2-PSK, Mixed WPA/WAP2-PSK

• Multiple SSID (4 SSIDs), BSSID

• Wireless MAC Filtering

• Wireless Client Isolation

• Wi-Fi Hotspot with captive portal

• RADIUS or integrated account database.

Serial RS-232 / RS-485

• DEC, DB-9

• Modbus/TCP, Telent Server, SSH Server,UDP Server/ Client, TCP Server/ Client

Global Navigation Satellite System(GNSS)*4

• GNSS engine for GPS or GLONASS system

Management

• Password protection for system management

• Web-based GUI for remote and local management

• Firmware upgrade and configuration data upload and download via web-based GUI

• CWMP(TR-069)*2, SNMP

• LTE Usage Allowance

• Remote System Log monitoring

• Scheduling Auto-Reboot

• Physical layer/protocol diagnostic test tool

Intelligent Ignition Sensing

 • For In-vehicle connectivity installations

Hardware Specifications

Physical Interface

• LTE: two(2) SMA Female Connectors

• Wireless: two(2) RP-SMA Female Connectors

• (Optional)GPS: one (1) SMA Female Connectors*4

• WAN: LTE and/or Ethernet WAN

• RS-232 / RS-485  (DCE, DB-9):one(1)port

• Ethernet LAN: 4-port 10/100/1000Mbps auto-crossover (MDI/ MDI-X) switch

• SIM Card: two (2) slots

• Reset Button

• Power Connector:4-Pin connector with ignition sense

• LED Indicators

Power Specifications

• Input: DC 10V ~ 56V with ignition sensing

Operating Requirements

• Operating: -40°C to 60°C (-40°F to 140°F)

• Humidity: 20 ~ 95% non-condensing
