Xentino DT670 is an 11ac dual band wall mount style wireless access point upgrade to the latest wireless-AC technology, fast data rate (900Mbps in 5G and 300Mbps in 2.4GHz) and dual band allowing content to download faster, large video or music files to sync more quickly and stream seamlessly. Embeded PoE, work in hotel, school, hospital mainly for a stable wireless networking.
Xentino DT670 is an 11ac dual band wall mount style wireless access point upgrade to the latest wireless-AC technology, fast data rate (900Mbps in 5G and 300Mbps in 2.4GHz) and dual band allowing content to download faster, large video or music files to sync more quickly and stream seamlessly. Embeded PoE, work in hotel, school, hospital mainly for a stable wireless networking.
DT670 is an 11ac dual band wall mount style wireless access point upgrade to the latest wireless-AC technology, fast data rate (900Mbps in 5G and 300Mbps in 2.4GHz) and dual band allowing content to download faster, large video or music files to sync more quickly and stream seamlessly. Embed PoE, work in hotel, school, hospital mainly for a stable wireless networking. Then work with Xentino ‘s Access Controller System and cloud management system, easy in central configuration, meet with different advertisement and multiple authentication requirement, professional and cost effectively in large area Wi-Fi solution.
Wireless AC Technology, more users
The DT670 AC dual band wall mount Wireless Access Point with Gigabit WAN port, offers AC technology 1200Mbps data rate for seamless/smoother video and music streaming. More users including computers, Internet-ready TVs, game consoles, and other Wi-Fi devices can access into this wireless networking
Support 802.11kvr Seamless Roaming
It support 802.11kvr seamless roaming, user will enjoy the freely networking without any suspend even the wireless signal switch from this AP to another AP.
Dual Band, 5G Priority, Less Interference
Double your network bandwidth with Dual-Band AC(2.4G and 5G) and 5G priority, designed to help avoid interference and maximize throughput. You can browse web pages, handle mails and chat over 2.4G while enjoying large-free HD multimedia and online gaming over 5G without worrying about interference.
Build in Wi-Fi Channel Analysis Tool for best channel
Build in Smart Channel Analysis Tool, help to select the less Wi-Fi Interference channels, ensure the stability wireless signal.
Power over Ethernet
DT670 AC AP has integrated IEEE 802.3af standard Power over Ethernet (PoE), for easy installation and lower cost. So it can be installed in areas where power outlets are not readily available, eliminating the mess of altering existing network infrastructure.
HARDWARE SPECIFICATIONS |
||
Chipset |
MT7628DAN+MT7613BEN |
|
Standard |
802.11ac/b/g/n |
|
Flash |
8M Flash |
|
Memory |
64M DDR |
|
Interface |
1 * 10/100 RJ45 WAN Port |
|
1 * 10/100 RJ45 LAN Port |
||
1* Reset / WiFi Switch On/Off button |
||
Antenna Type |
On board WiFi antenna 2.4G: 2*2dBi omni antenna 5.8G: 2*2dBi omni antenna |
|
Power Supply |
48V PoE, IEEE 802.3af standard |
|
Power Consumption |
≤ 8W |
|
Size |
87*86*35.8mm |
|
WIRELESS FEATURES |
||
Wireless Standards |
IEEE 802.11ac/n/a 5GHz; IEEE 802.11n/g/b 2.4GHz |
|
Frequency |
5GHz : 5.150GHz~5.850GHz 2.4GHz: 2.4GHz – 2.484GHz |
|
Signal Rate |
5GHz: Up to 900Mbps; 2.4GHz: Up to 300Mbps |
|
RF Power (2.4GHz) |
802.11b 11M 17±2dBm 1M 19±2dBm 802.11g 54M 16±2dBm 6M 18±2dBm 802.11n HT20 MCS7 15±2dBm MCS0 17±2dBm 802.11n HT40 MCS7 14±2dBm MCS0 16±2dBm |
|
RF Power (5GHz) |
802.11a 54M 16±2dBm 6M 18±2dBm 802.11n HT20 MCS7 15±2dBm MCS0 17±2dBm 802.11n HT40 MCS7 14±2dBm MCS0 16±2dBm 802.11ac HT80 MCS9 13±2dBm MCS0 15±2dBm |
|
Receive Sensitivity (2.4GHz) |
802.11b 11M -83dBm 1M -94dBm 802.11g 54M -72dBm 6M -90dBm 802.11n HT20 MCS7 -70dBm MCS0 -88dBm 802.11n HT40 MCS7 -68dBm MCS0 -86dBm |
|
Receive Sensitivity (5GHz) |
802.11a 54M -72dBm 6M -90dBm 802.11n HT20 MCS7 -70dBm MCS0 -88dBm 802.11n HT40 MCS7 -68dBm MCS0 -86dBm 802.11ac HT80 MCS9 -58dBm MCS0 -80dBm |
|
Wireless |
Auto-Channel selection Distance Control (802.1x Ack timeout) Multiple SSID (4 SSID for 2.4G, 4 SSID for 5.8G) BSSID |
|
EVM |
2.4G: 802.11b: ≤-10 dB; 802.11g: ≤-25dB; 802.11n: ≤-28 dB 5G: 802.11a: ≤-25 dB; 802.11n: ≤-28 dB; 802.11ac: ≤-32 dB |
|
PPM |
±20ppm |
|
Max Access Users |
128 |
|
Operation Mode |
Wireless AP, Gateway, Wi-Fi Repeater |
|
Wireless Security |
64/128-bit WPA / WPA2, WPA-PSK/ WPA2-PSK encryption and RADIUS 802.1x |
|
ESD - I |
Contact Discharge:±6KW, Air discharge:±8KV |
|
ESD- II |
Contact Discharge:±8KW, Air discharge:±16KV |
|
LED Status |
WAN, LAN, SYS |
MANAGEMENT |
|
System Settings |
Web-based configuration / Software AC controller and Hardware AC controller management |
Firmware Upgrade |
Upgrade firmware via web browser or AC controller |
Administration |
Admin Password can be configured |
System monitoring |
Watch dog, Status in hand , useful statistic and Event log |
Logs |
Supports local logs, logs host, logs file export |
Reset |
Reset or factory defaults |
Backup |
Restore settings & configuration of the device to local file, Scheduled reboot |
