Xentino RL212 4G LTE Cat12 1200M Wireless Router
Xentino RL212 is an 11ax standard dual band indoor 4G/LTE wireless router. Comply with IEEE 802.11ax/ac/b/g/n 2x2 MIMO standard, the data rate up to 1200Mbps, more than 30 end users can access into it with embedded SIM card slot, build in LTE module(CAT12 with 600/150Mbps). Device has 2*10/100/1000Mbps LAN ethernet ports and 1*10/100/1000Mbps WAN Ethernet port.
Xentino RL212 is an 11ax standard dual band indoor 4G/LTE wireless router. Comply with IEEE 802.11ax/ac/b/g/n 2x2 MIMO standard, the data rate up to 1200Mbps, more than 30 end users can access into it with embedded SIM card slot, build in LTE module(CAT12 with 600/150Mbps). Device has 2*10/100/1000Mbps LAN ethernet ports and 1*10/100/1000Mbps WAN Ethernet port.
Xentino RL212 is an 11ax standard dual band indoor 4G/LTE wireless router. Comply with IEEE 802.11ax/ac/b/g/n 2x2 MIMO standard, the data rate up to 1200Mbps, more than 30 end users can access into it with embedded SIM card slot, build in LTE module(CAT12 with 600/150Mbps). Device has 2*10/100/1000Mbps LAN ethernet ports and 1*10/100/1000Mbps WAN Ethernet port.
OVERVIEW
RL212 is an 11ax standard dual band indoor 4G/LTE wireless router. Comply with IEEE 802.11ax/ac/b/g/n 2x2 MIMO standard, the data rate up to 1200Mbps, more than 30 end users can access into it with SIM card slot, build in LTE module. It supports FDD-LTE/TDD-LTE for worldwide use CAT12 with 600Mbps Download and 150Mbps Upload speeds. Device has 2*10/100/1000Mbps LAN ethernet ports and 1*10/100/1000Mbps WAN Ethernet port.
MAIN FEATURES
- Comply with IEEE 802.11b/g/n/ac/ax Standard, 2.4GHz and 5.8GHZ frequency, the data rate is 1200Mbps for faster Wi-Fi speed.
- Build in 4/LTEG SIM card slot, support LTE-TDD/LTE-FDD, WCDMA/CDMA and GSM networking. The band is adjustable, can comply with all operator in the world.
- High RF power design, with 2x2 MIMO 2.4G/5.8G antenna, more wireless coverage, better signal strength and more stable performance.
- It supports VPN (L2TP, PPTP), meet with industrial applications such as chain stores, ATM...
- Firmware support cloud remote configure and management, hardware with watchdog function, device can auto-reboot and auto-recovery if have problems, no extra maintenance fee.
TECHNICAL SPECIFICATION
|
Part Number |
RL212 |
||
|
WWAN |
Platform |
Qualcomm SDX12 |
|
|
Frequency |
LTE |
LTE FDD: B1/B3/B5/B7/B8/B20/B28/B32 LTE TDD: B38/B40/B41(120M)/B42/B43/B48 |
|
|
CA Combinations |
3CA(DL): 1A-3A-5A/7A/8A/20A/28A/32A/38A/40A/41A/42A; 1A-5A-7A; 1A-7A-7A/8A/20A/28A; 1A-20A-32A; 1A-41A-42A; 1A-1A-28A; 1A-7C/41C/42C; 3A-3A-7A/20A; 3A-5A-7A; 3A-7A-7A/8A/20A/28A; 3A-5A-7A; 3A-3A-8A; 3A-8A-38A; 3A-28A-40A; 3A-7C/40C/41C/42C; 3A-7B; 7A-7A-8A; 7A-20A-32A; 28A-40C; 41A-41C/42C; 3C-5A/7A/8A/20A/28A/41A; 7B-28A; 7C-8A/20A; 7C-28A; 41C-42A; 40D; 41D 2CA(DL): 1A-1A/3A/5A/7A/8A/20A/28A/32A/38A/40A/41A/42A; 3A-3A/5A/7A/8A/20A/28A/32A/38A/40A/41A/42A; 5A-7A; 7A-7A/8A/20A/28A/32A;20A-32A; 28A-40A; 40A-40A; 41A-41A/42A;1C;3C;5B;7C;38C;40C;41C;42C 2CA(UL): 1A-3A/5A/7A/8A,3A-5A/7A/8A/20A/28A; 3C;5B;7C;38C;40C;41C;42C |
||
|
UMTS |
B1/B3/B5/B8 |
||
|
Antenna |
Built in |
DL 4*4 MIMO (B1/B3/B7/B38/B40/B41/B42) |
|
|
Power Class |
LTE FDD |
Power Class 3 (23 ± 2dBm) |
|
|
UMTS |
Power Class 3 (23.5dBm ± 2dBm) |
||
|
Data Rate |
LTE |
3GPP R12 LTE Cat12, Downlink/Uplink: 600Mbps/150Mbps |
|
|
WCDMA |
3GPP R9, Downlink/Uplink: 42Mbps/5.76Mbps |
||
|
WLAN |
Wi-Fi |
Chipset |
MTK MT7621A |
|
Frequency |
Dual-band, 2.4GHz & 5GHz |
||
|
Protocol |
802.11 a/b/g/n/ac/ax , 2*2 MIMO |
||
|
Antenna |
2.4GHz Built-in 2*2MIMO |
||
|
Clients |
32 |
||
|
Data Rate |
802.11b |
Up to 11 Mbps |
|
|
802.11g |
Up to 54 Mbps |
||
|
802.11n |
Up to 300 Mbps |
||
|
802.11ac |
Up to 867 Mbps |
||
|
802.11ax |
Up to 1201Mbps (80MHz) |
||
|
Hardware |
Interface |
LAN/WAN |
3* Giga Ports: 1xWAN+2xLANs |
|
USIM |
Single, 4FF Nano SIM |
||
|
DC Jack |
12V/2A |
||
|
LED |
Network |
4G/3G Network Status LED *1 |
|
|
Wi-Fi |
1 LEDs for LAN/WAN Indicator (Single: Green *1) |
||
|
Button |
WPS |
Enable/Disable WPS |
|
|
Reset |
Restore to Factory Settings |
||
|
Software |
Management |
WebUI- Management |
|
|
TR069 Remote Management |
|||
|
Mobile APP Management (Optional) |
|||
|
Network Setting |
APN Management |
||
|
Network Select |
|||
|
Statistics |
|||
|
Gateway |
DHCP Server |
||
|
Dynamic/Static IP |
|||
|
ARP |
|||
|
ICMP |
|||
|
LAN IP |
|||
|
IPv4/v6 Dual stack |
|||
|
Routing |
|||
|
Security |
Firewall Switch |
||
|
MAC ACL |
|||
|
IP address Filtering |
|||
|
VPN passthrough, L2TP, PPTP |
|||
|
DMZ |
|||
|
SIP ALG |
|||
|
uPnP |
|||
|
NAT |
|||
|
DNS |
|||
|
Wi-Fi |
SSID Broadcast and Hiding |
||
|
WPS |
|||
|
Encryption: WEP, AES, TKIP+AES |
|||
|
OPEN, WEP, WPA/WPA2-PSK |
|||
|
MAC Filter |
|||
|
Software |
OS |
Windows 7，Windows 8.1，Windows 10 or higher |
|
MAC OS X 10.14 or higher |
||
|
Browser |
IE9+, Edge, Firefox, Google Chrome, Safari etc. |
|
|
Environment |
Operating Temperature |
0°C to 45°C |
|
Storage Temperature |
-20°C to 60°C |
|
|
Operation Humidity |
10%~90% non-condensing |
|
|
Storage Humidity |
5%~90% non-condensing |
