Ürün Bilgileri

Synology RS2423+, çeşitli kurumsal ortamlarda kullanılabilecek şekilde tasarlanmış, 2U 12 yuvalı depolama sunucusu. 24 sürücüye kadar ölçeklendirilebilen ünite, uygun maliyetli dosya yönetimi için tasarlanmıştır ve veri ayak izi sürekli olarak büyüyen işletmelere özel, güçlü yedekleme özellikleri içerir. 3.500 MB/sn'ye kadar sıralı okuma ve 1.700 MB/sn'ye kadar sıralı yazma performansı sunar; SSD önbelleği ve 1/10/25 GB Ethernet ile isteğe bağlı olarak geliştirilebilir.

CPU ModelAMD Ryzen V1780BCPU Quantity1CPU Architecture64-bitCPU Frequency4-core 3.35 (base) / 3.6 (turbo) GHzHardware Encryption Engine (AES-NI)

System Memory8 GB DDR4 ECC UDIMMMemory Module Pre-installed8 GB (8 GB x 1)Total Memory Slots2Maximum Memory Capacity32 GB (16 GB x 2)Notes

• Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
• Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.
• For more information about the recommended memory configurations, please check the Hardware Installation Guide of your Synology product.

Drive Bays12Maximum Drive Bays with Expansion Unit24 (RX1223RP x 1)Compatible Drive Type* (See all supported drives)

• 3.5" SATA HDD
• 2.5" SATA SSD

Hot Swappable Drive*Notes

• Synology only guarantees full functionality, reliability, and performance for Synology drives listed on the compatibility list. The use of non-validated components may limit certain functionality and result in data loss and system instability.
• "Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.

RJ-45 1GbE LAN Port*2 (with Link Aggregation / Failover support)RJ-45 10GbE LAN Port1USB 3.2 Gen 1 Port*2Expansion Port1Notes

• This device's 1GbE LAN ports have a maximum transmission unit (MTU) size of 1,500 bytes.
• The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019.

PCIe Expansion1 x Gen3 x8 slot (x4 link)

Internal Drives

• Btrfs
• EXT4

External Drives

• Btrfs
• EXT4
• EXT3
• FAT
• NTFS
• HFS+
• exFAT

Form Factor (RU)2USize (Height x Width x Depth)RS2423+ :88 mm x 482 mm x 552 mmRS2423RP+ :88 mm x 482 mm x 578 mmWeightRS2423+ :11.5 kgRS2423RP+ :11.9 kgRack Installation Support*4-post 19" rack (Synology Rail Kit - RKS-02)NotesThe rail kit is sold separately

System Fan60 mm x 60 mm x 3 pcsFan Speed Mode

• Full-Speed Mode
• Cool Mode
• Quiet Mode

Easy Replacement System FanPower RecoveryNoise Level*RS2423+ :52.3 dB(A)RS2423RP+ :56.2 dB(A)Scheduled Power On / OffWake on LAN / WANPower Supply Unit / AdapterRS2423+ :500 WRS2423RP+ :350 WRedundant Power SupplyRS2423+ :-RS2423RP+ :AC Input Power Voltage100 V to 240 V ACPower Frequency50/60 Hz, Single PhasePower ConsumptionRS2423+ :119.95 W (Access) 46.21 W (HDD Hibernation)
RS2423RP+ :114.86 W (Access) 42.33 W (HDD Hibernation)British Thermal UnitRS2423+ :409.56 BTU/hr (Access) 157.78 BTU/hr (HDD Hibernation)
RS2423RP+ :392.18 BTU/hr (Access) 144.53 BTU/hr (HDD Hibernation)Notes

• For more information on how power consumption is measured, refer to this article.
• Noise Level Testing Environment: A Synology NAS loaded with Synology 480GB SAT5200-480G solid-state drive(s) in idle state. Each G.R.A.S. type 40AE microphone is placed at a 1-meter distance from the front and rear of a Synology NAS. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%

Operating Temperature0°C to 35°C (32°F to 95°F)Storage Temperature-20°C to 60°C (-5°F to 140°F)Relative Humidity5% to 95% RH

• FCC
• CE
• BSMI
• VCCI
• RCM
• UKCA
• EAC
• CCC
• KC
• UL

3-year hardware warranty, extendable to 5 years with EW202 or Extended Warranty PlusNotes

• Availability varies by region. Before purchasing, please visit the official web pages of EW201/202 and Extended Warranty Plus for a list of eligible regions.
• The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)

RoHS Compliant

RS2423+ :

• Main Unit X 1
• Accessory Pack X 1
• AC Power Cord X 1
• Quick Installation Guide X 1

RS2423RP+ :

• Main Unit X 1
• Accessory Pack X 1
• AC Power Cord X 2
• Quick Installation Guide X 1

• DDR4 ECC UDIMM: D4EU01-8G/D4EU01-16G
• Expansion Units: RX1223RP
• 3.5" SATA HDD: HAT5300
• 2.5" SATA SSD: SAT5210
• M.2 SSD & 10GbE Combo Adapter Card: E10M20-T1
• M.2 SSD Adapter Card: M2D20
• 25GbE Network Interface Card: E25G21-F2
• 10GbE Network Interface Card: E10G21-F2/E10G18-T2/E10G18-T1
• Rail Kit Sliding: RKS-02
• VisualStation: VS360HD
• Surveillance Device License Pack

Notes

• Certain items may not be available in your location. Please contact your local distributors for more information.
• All memory modules will operate at the maximum frequency specified by the CPU manufacturer.
