Architecture

Active-Active dual-controller

Storage OS

QSM 3 Specification Details

CPU

Processor

Intel® Xeon®

CPU Architecture

64-bit

CPU Frequency

Quad-Core (Also support 8 core model)

Memory

System Flash

16GB USB DOM

Memory Module Pre-installed

16GB DDR4 ECC DIMM (per controller)

Total Memory Slots

4 (per controller)

Memory Expandable up to

128GB (per controller)

Notes

-

Storage

Drive Bays

3.5" Slot x 16

Maximum Drive Bays with Expansion Unit

424

Compatible Drive Type

3.5" SAS HDD

3.5" SAS SED HDD

3.5" NL-SAS HDD

3.5" NL-SAS SED HDD

2.5" SAS SSD

2.5" SAS SED SSD

2.5" SATA SSD

2.5" SATA SED SSD

2.5" SAS HDD

2.5" SAS SED HDD

2.5" NL-SAS HDD

2.5" NL-SAS SED HDD

Drive Interface

SAS 12Gb/s and SATA 6Gb/s

(backward compatible with SAS 6Gb/s and SATA 3Gb/s)

Maximum Internal Raw Capacity

256TB

Maximum Raw Capacity with Expansion Units

5968TB

Hot Swappable Drive

Notes

• For more information, please refer to compatibility matrix and hardware manual
• Maximum internal raw capacity= 16 TB drive x 16
• Capacity may vary by RAID types
• In dual-controller system, 2.5 SATA HHD need 6G MUX board

External Port

USB 2.0 Port

1 (Front)

USB 3.0 Port

2 (Rear)

HDMI Port

-

Others

UPS Port x1
Controller port x 1

Notes

-

Connectivity Port

1GbE RJ45 LAN Port

1 (Onboard)

10GbE RJ45 LAN Port

2 (Onboard)
2 iSCSI (Option: HQ-10G2T)

10GbE SFP+ LAN Port

4 iSCSI (Option: HQ-10G4S2)

Thunderbolt 3

-

25GbE SFP28 LAN Port

2 iSCSI (Option: RHCE25P2)

16Gb SFP+ Fibre Channel

4 FCP (Option: HQ-16F4S2)
2 FCP (Option: HQ-16F2S2)

32Gb SFP28 Fibre Channel

2 FCP (Option: RHCF32P2)

Notes

For more information, please refer to accessory book

Please refer to the section below for expansion slot specification

RHCE25P2, HQ-16F2S2, RHCF32P2 Option card will be launch in the 4th quarter of 2020

Expansion Port

12Gb/s SAS Wide Port

2 (Onboard)

Notes

-

PCIe Expansion

Gen3x8 Slot

-

Gen3x4 Slot

-

Notes

-

Host Card Expansion

Gen3x8 Slot

1

Gen2x4 Slot

1

Notes

Gen2x4 slot provides 20Gb bandwidth

Appearance

Dimension (H x W x D) (mm)

130.3 x 438 x 515

Chassis Form Factor

MAYIS" Rackmount 3U 16 Bay

Net Weight (kg)

22

Gross Weight (kg)

31.1

Notes

-

Memory Protection

Cache-to-Flash Module

Battery Backup Module + Flash Module

-

Notes

Does not need Battery Backup Module

Others

System Fan

4 pcs

Replaceable System Fan

Power Recovery

Scheduled Power On/Off

-

Wake on LAN/WAN

Power Supply Unit / Adapter

770W/850W x 2 (80 PLUS Platinum)

Redundant Power Supply

AC Input Power Voltage

100V-240V

Power Frequency

50-60 Hz, Single Phase

Power Consumption

534W

British Thermal Unit

1,822BTU

LCM Support

Notes

-

Environment Temperature

Operating Temperature

0 to 40°C

Storage Temperature

-10°C to 50°C

Operating Relative Humidity

20% to 80% non-condensing

Non-operating Relative Humidity

10% to 90%

Notes

-

Certification

Certifications

CE

FCC

CCC

BSMI

VCCI

KCC

Notes

-

Warranty

Standard Warranty

3 years

Notes

-
