Synology DS423Plus all in one 4Bay NAS

Synology DS423Plus all in one 4Bay NAS

Synology

Synology DS423Plus all in one 4Bay NAS güçlü bir 4 yuvalı 3,5" veya 2,5" SATA SSD/HDD takılabilen ağ bağlantılı depolama çözümüdür. olup Intel Celeron J4125 dört çekirdekli 2,0 GHz işlemci, 2 GB bellek, 2 adet USB 3.2 bağlantı noktası ve çift 1 GbE bağlantı noktası ile donatılmıştır.

Synology DS423Plus all in one 4Bay NAS güçlü bir 4 yuvalı 3,5" veya 2,5" SATA SSD/HDD takılabilen ağ bağlantılı depolama çözümüdür. olup Intel Celeron J4125 dört çekirdekli 2,0 GHz işlemci, 2 GB bellek, 2 adet USB 3.2 bağlantı noktası ve çift 1 GbE bağlantı noktası ile donatılmıştır.

CPU
 CPU Model Intel Celeron J4125
  CPU Quantity 1
  CPU Architecture 64-bit
  CPU Frequency 4-core 2.0 (base) / 2.7 (turbo) GHz
  Hardware Encryption Engine (AES-NI)
Memory
 System Memory 2 GB DDR4 non-ECC SODIMM
  Total Memory Slots 1
  Maximum Memory Capacity 6 GB (2 GB + 4 GB)
  Notes
  • Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
  • Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.
  • For more information about the recommended memory configurations, please check the Hardware Installation Guide of your Synology product.
Storage
 Drive Bays 4
  M.2 Drive Slots 2 (NVMe)
  Compatible Drive Type* (See all supported drives)
  • 3.5" SATA HDD
  • 2.5" SATA SSD
  • M.2 2280 NVMe SSD
  Hot Swappable Drive*
  Notes
  • The hot swappable drive feature is not supported by M.2 SSD slots.
  • "Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
External Ports
 RJ-45 1GbE LAN Port* 2 (with Link Aggregation / Failover support)
  USB 3.2 Gen 1 Port* 2
  Notes
  • This device's 1GbE LAN ports have a maximum transmission unit (MTU) size of 1,500 bytes.
  • The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019.
File System
 Internal Drives
  • Btrfs
  • EXT4
  External Drives
  • Btrfs
  • EXT4
  • EXT3
  • FAT
  • NTFS
  • HFS+
  • exFAT
Appearance
 Size (Height x Width x Depth) 166 mm x 199 mm x 223 mm
  Weight 2.18 kg
Others
 System Fan 92 mm x 92 mm x 2 pcs
  Fan Speed Mode
  • Full-Speed Mode
  • Cool Mode
  • Quiet Mode
  Brightness Adjustable Front LED Indicators
  Power Recovery
  Noise Level* 19.8 dB(A)
  Scheduled Power On / Off
  Wake on LAN / WAN
  Power Supply Unit / Adapter 90 W
  AC Input Power Voltage 100V to 240V AC
  Power Frequency 50/60 Hz, Single Phase
  Power Consumption 28.3 W (Access)
8.45 W (HDD Hibernation)
  British Thermal Unit 96.5 BTU/hr (Access)
28.81 BTU/hr (HDD Hibernation)
  Notes
  • For more information on how power consumption is measured, refer to this article.
  • Noise testing was conducted with the Synology system fully installed with Synology SATA HDDs and in an idle stae. Two G.R.A.S. Type 40AE microphones are placed at a 1 m distance from the front and rear of the device. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%
Temperature
 Operating Temperature 0°C to 40°C (32°F to 104°F)
  Storage Temperature -20°C to 60°C (-5°F to 140°F)
  Relative Humidity 5% to 95% RH
Certification
  • FCC
  • CE
  • BSMI
  • VCCI
  • RCM
  • UKCA
  • EAC
  • CCC
  • KC
Warranty
 3-year hardware warranty, extendable to 5 years with EW201 or Extended Warranty Plus
  Notes
  • Availability varies by region. Before purchasing, please visit the official web pages of EW201/202 and Extended Warranty Plus for a list of eligible regions.
  • The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
Environment
 RoHS Compliant
Packaging Content
  • Main Unit X 1
  • Accessory Pack X 1
  • AC Power Adapter X 1
  • AC Power Cord X 1
  • RJ-45 LAN Cable X 2
  • Quick Installation Guide X 1
Optional Accessories
  Notes All memory modules will operate at the maximum frequency specified by the CPU manufacturer.

Notes:

  1. Model specifications are subject to change without prior notice.
  2. The figures are based on Synology internal testing. Each performance test is done individually. No other services or applications are processed at the same time.
  3. The actual performance may be lower than lab testing figure due to differences in server configuration, deployment, and the number of active operations.
  4. If usage requirements exceed the specifications above, please contact our regional partners for professional advice.

Bu ürüne ait özellikler veritabanımızda bulunmamamktadır.

DS423Plus Datasheet
DS423Plus Broşür
